- Capacity: 50L
- Temperature range: Oven: 80-200℃; Incubator: RT+5-80℃
- Test hole: Optional φ25, 50, 80mm
- Safety device: Leakage protector/Over-temperature alarm
Dual Purpose (Oven/Incubator), DOI-50Z
Description
It can be used as an incubator for industrial and mining enterprises, laboratories, scientific research units, etc. to cultivate viruses and bacteria; it can also be used as a drying oven for drying, baking, melting wax, and sterilization.
Features
Energy-saving
- The sealing ring of incubator adopts a new type of synthetic silicone sealing strip, which effectively prevents heat loss.
- Automatically adjust the control parameters according to the ambient temperature and load to achieve the optimal heating method and reduce energy consumption.
Intelligent LCD control
- Large-screen LCD display, real-time parameter display, simple and convenient operation.
- Menu-type operation interface, simple and convenient operation, can quickly set temperature and time parameters.
- Running function: fixed value running, timing running, the screen displays “END” when the running time is completed, accompanied by a buzzer reminder.
Internal circulation system
- Adoptshigh-quality fan and large impeller fan, the machine has higher ventilation efficiency and better temperature uniformity.
- The circulation system adopts the back suction and the air circulation on both sides
- The shelfis laser hollowed out with round holes for better ventilation and better temperature uniformity.
Dedicated sheet metal processing
- The shelf can be disassembled and can be freely adjusted up and down, with a minimum spacing of 30mm.
- The inner tank is made of high-quality brushed stainless steel, with strong corrosion resistance.
- Built in observation window to make the objects in the chamber clear at a glance.
- The anti-scalding design of the door handle makes it easy to open and close the door.
Safety
- Equipped with leakage protection device to ensure the safety of operators and other equipment in the laboratory.
- The insulation material is made of high-quality aluminum silicate silk cotton, and the insulation layer of the box is thickened.
- With limited temperature control sound and light alarm system.
- Self-diagnosis function: display fault information, which is convenient for judging the fault point.
Specifications
Model | DOI-50Z | |
Capacity(L) | 50 | |
Circulation | Forced air convection | |
Dimension | Internal | 420*350*500 |
(W*D*H) | (mm) | |
External | 710*520*520 | |
(mm) | ||
Temperature | Range | Oven: 80-200 |
(℃) | Incubator:RT+5-80 | |
Fluctuation | ±0.5 | |
(℃) | ||
Resolution | 0.1 | |
(℃) | ||
Uniformity | 25% | |
(℃) | ||
Sensor | PT100 | |
Controller | PID | |
Display | LCD | |
Timer(min) | 1-9999 | |
Material | Internal | Stainless steel |
External | Electro-galvanized steel with antimicrobial powder coating | |
Shelves | 2 | |
Test Hole (mm) | Optional φ25,50,80 | |
Safety Device | Leakage protector/Over- temperature alarm | |
Electricity | Voltage/Frequency | 220/50 |
(V/Hz) | ||
Consumption | 850 | |
(W) | ||
N. W./G.W. | 42/45 | |
(kg) | ||
Shipping Dimension (W*D*H) | 770*640*650 | |
(mm) | ||
Optional | 1.Independent temperature limiting controller | |
2.Intelligent LCD procedure temperature controller(Optional USB,RS485/232 and printer) |
