PCR Cabinet, LCB-VII Series
Description
LCB-V800II LCB-V1000II LCB-V1300II
LCB-V1600II LCB-V1800II
This product is mainly used to standardize the safe operation of chemicals and ensure the safety of experimental personnel and property. The product is equipped with a flexible modular filtration system and fan system, which can effectively filter different substances such as gas, powder and mixture of gas and powder. After filtration, clean air circulates indoors.
- Metal part material: galvanized steel plate, coated with acid and alkali resistant epoxy polyester coating;
- The operating table is made of epoxy resin board；
- Features of cold fluorescent lighting: safe service life of more than 100,000 hours;
- LED display: 3.5-inch LED smart display, which displays the filter operating temperature, fan speed, instant surface wind speed, filter life countdown, and filter outlet TVOC concentration probe; The fan speed can be adjusted by the user according to usage conditions to ensure negative pressure in the cabinet.
- The TVOC concentration display accuracy at the filter outlet is 0.1PPM, and the alarm value can be set by yourself.
- The surface wind speed detection probe needs to be located on the front baffle of the fume hood, with a display accuracy of 0.1m/s.
- The filtration system has modular functions and can be equipped with corresponding filters for liquid or dust and mixing experiments, and has adsorption functions for 500 common chemical substances.
Specifications
| Product model | LCB-V800II | LCB-V1000II | LCB-V1300II | LCB-V1600II | LCB-V1800II |
| Internal Dimensions(W*D*H)(mm) | 786*560*760 | 986*560*760 | 1286*690*760 | 1586*690*760 | 1786*690*760 |
| External Dimensions(W*D*H)(mm) | 800*620*890~1350 | 1000*620*890~1350 | 1300*790*920~1502 | 1600*790*930~1502 | 1800*790*940~1502 |
| Filter Number | 2 | 2 | 4 | 6 | 8 |
| Air volume(m³/h) | 240 | 240 | 480 | 720 | 960 |
| Surface Wind Speed (m/s) | 0.4~0.6 | 0.4~0.6 | 0.4~0.6 | 0.4~0.6 | 0.4~0.6 |
| Noise(dBA) | ≤50 | ≤50 | ≤54 | ≤57 | ≤57 |
| Standard Accessories | Fluorescent lamp*1 | Fluorescent lamp*1 | Fluorescent lamp*2 | Fluorescent lamp*3 | Fluorescent lamp*4 |
| Filter*2 | Filter*2 | Filter*4 | Filter*6 | Filter*8 | |
| Epoxy resin countertop*1 | Epoxy resin countertop*1 | Epoxy resin countertop*1 | Epoxy resin countertop*1 | Epoxy resin countertop*1 | |
| Optional Accessories | Painted explosion-proof tempered glass countertop;Base Cabinet;
Fluorescent lamp; Filter（HF4TY,HF4AM,HF4FM,HF4HP,HF4YJ） |
||||
Filter type:
HF4TY: It has strong adsorption capacity for acidic gases and is compatible with the adsorption of organic gases. It is a universal filter.
HF4AM: mainly for ammonia gases, followed by organic gases.
HF4FM: mainly for formaldehyde, followed by organic gases.
HF4HP: mainly for particle filtration, for particles larger than 0.3μm, the filtration efficiency is 99.995%.
HF4YJ: mainly for organic gases, followed by acidic gases.
