Tablet Hardness Tester, THDT-2

  • Hardness test range: 2-200N  0.2KG-20KG【Customizable 500N(50KG)】
  • Resolution: 0.1N  0.01Kg
  • Hardness measurement accuracy: range±0.5%
  • Tablet measurement diameter: 2-40mm

Share the product


Tablet hardness tester is used to measure the crushing hardness of tablets.

High-precision pressure sensor ensures the precision and reproducibility of test.
High-definition LCD is adopted, the display contents are rich; users can enjoy intelligent operations according to the screen tips, Chinese character hint and quantitative index are provided for each operational process.
Optional for measuring mode: Manual single tablet/automatic continuation.
The system can realize automatic tablet compressing, automatic display, automatic latching, automatic reset, automatic cycle test, automatic linear error correction and automatic fault diagnosis.
Strong data processing ability; statistics, analysis, printing and display are available for test result. It can submit reports of maximum and minimum values, standard deviation and range of change of the test sample.
Automatic calculation of tablet return travel can compress your test duty time.
One-key conversion of measuring unit (Newton-Kilogram)
New type front paper change mini-printer.
Convenient and efficient measurement of tablet diameter.


Hardness test range 2-200N  0.2KG-20KG【Customizable 500N(50KG)】
Resolution 0.1N  0.01Kg
Hardness measurement accuracy range±0.5%
Tablet measurement diameter 2-40mm
Repeated measurement error ±1%
Measuring unit Newton (N) Kilogram(KG)
Overall dimensionsL*W*H 400mm*240mm*140mm
