Vertical Laminar Flow Hood, LCB-VF Series

  1. Vertical type Laminar Flow Hood
  2. Work Surface Height: 750mm
  3. Airflow Velocity: Adjustable, 0.2~0.5 m/s
  4. HEPA Filter Efficiency: > 99.995% at particle size of 0.3 μm
  5. Control System: Microprocessor controller with LCD display

Share the product



Vertical Laminar Flow Hood / Cabinet (also called clean bench) provides sample protection as purified air travels across the working zone of the cabinet in a vertical, unidirectional stream and leaves the main work chamber across the entire open front of the cabinet.

Most vertical Laminar Flow Hood also have perforations at the back wall of the work zone which are designed to eliminate air turbulence and the possibility of dead air corners in the work zone.


  • Microbiology (non-pathogenic)
  • Forensics
  • Sterile product compounding


Humanized Features

  • Ergonomic Control Panel Location, centered and angled down for an easy reach & viewing
  • Brushed stainless steel work surface is for easy cleaning
  • The non-direct light source design can effectively relieve the operator’s visual fatigue under the condition of ensuring the illumination
  • Intuitive and easy-to-use microprocessor controller with LCD display, graphical and digital display of the operating status of each function, such as filter life, UV life etc.

 Safety Features

  • Front sliding sash interlock with fan and UV lamp
  • UV sterilization with UV lamp timing function
  • Front sash and side windows are made of UV-resistant tempered glass
  • The host and sockets have independent capacitors to prevent current overload

Convenience Features

  • Memory function in case of power-failure
  • HEPA filter and UV life indicators facilitate a timely replacement plan
  • Two side glass windows installed for easy experiment observation
  • Easy-to-change pre-filter installed could extend the HEPA filter’s lifetime
  • Equipped with temperature sensor to show the real temperature during operation
  • Waterproof socket provide convenience for small instruments to be used in the operating area


External Dimensions
1050*710*1850 1320*710*1850 1625*710*1850 1930*710*1850
Internal Dimensions
950*615*625 1220*615*625 1525*615*625 1830*615*625
Control System Microprocessor controller with LCD display, graphical and digital display of the operating status of each function.
Work Surface Height 750mm
Airflow Velocity Adjustable, 0.2~0.5 m/s
HEPA Filter Efficiency > 99.995% at particle size of 0.3 μm
Dimensions(W*D*H)(mm) 895*470*70 1190*470*70 1505*470*70 895*470*70
Quantity 1pc 1pc 1pc 2pcs
Pre-Filter Material made of washable polyester fiber
Dimensions(W*D*H)(mm) 500*425*2 800*425*2 800*425*2 1000*425*2
Quantity 1pc
Sound Emission ≤62dB(A)
Lighting Lamp 6.5W*1 9.6W*1 9.6W*1 6.5W*2
LED Type, Intensity ≥900Lx
UV Lamp 20W*1 30W*1 30W*1 20W*2
With timing function, Interlock with front sliding sash. Emission of 253.7 nanometers for best sterilization effect.
Power Consumption 155W 285W 285W 300W
Doesn’t include external device connected via power socket
Cabinet Construction Main Body: Electro-galvanized steel with antimicrobial Powder Coating
Work Zone: Stainless steel, grade 304
Manual Sliding Sash: 5 mm UV Resistant Tempered Glass with counter-balance system and ergonomic handle
Side Windows: 5 mm UV Resistant tempered glass
Electricity AC220V ±10%, 50/60Hz,1P
Standard Accessories Base stand*1;
LED lamp*1(only 2 for LCB-V6F);
UV lamp*1(only 2 for LCB-V6F);
Waterproof socket*2 (only 1 for LCB-V3F);
Foma casters*4
Optional Accessories Wind speed sensor; Gas tap;Water tap;Casters with brakes; Hook and hook bar
Shipping Weight(kg) 225 255 285 330
Shipping Dimensions(W*D*H)(mm) 1010*1190*1420 1460*990*1325 1765*990*1325 2070*990*1325
Shipping Volume (m3) 1.56 1.92 2.3 2.7
