Rotary evaporator, also known as rotary evaporator, is mainly a common laboratory equipment composed of motors, distillation bottles, heating pots, condenser tubes and other parts.

The development history of rotary evaporator

1. Wool condenser

Ancient Greek sailors noticed fog condensation droplets on the sails, and sailors placed wool over heated jars to obtain fresh water, which was later known as a wool condenser.

2. Aristotle’s research

In the ancient Greek era in 350 BC, Aristotle studied the principles of distillation and condensation, and discovered the important circulation law of water in nature. Seawater becomes potable water.”

3. The research of the alchemists

In the 2nd century AD, alchemists developed the earliest copper distillation apparatus – the “still pot”.

4. The emergence of vacuum distillation

In the 17th century, Irish physicist Robert Boyle* carried out the revolutionary vacuum distillation, which proved the relationship between pressure and boiling point, and the distillation speed was greatly improved.

5. Rotating distillation flasks and commercial rotary evaporators

In the 1950s, scientists C.C.Draig and M.E.Volk proposed the concept of rotating flasks to achieve better mixing and larger area heating of samples. At the same time, the first commercial rotary evaporator was born.

6. The era of intelligent rotary steaming

In the 21st century, the wave of artificial intelligence is sweeping. The automation process of the laboratory is constantly advancing, and the intelligent rotary evaporation has become the standard configuration of the modern laboratory.

Advantages and disadvantages of rotary evaporator

Advantages

1. All rotary evaporators have a built-in lift motor, which can automatically lift the flask to the position above the heating pot when the power is turned off.

2. Due to the centripetal force and friction between the liquid sample and the evaporating bottle, the liquid sample forms a liquid film on the inner surface of the evaporating bottle, and the heating area is large;

3. The force generated by the rotation of the sample effectively inhibits the boiling of the sample. Combined with these features and their convenience, modern rotary evaporators can be used to quickly and gently distill most samples, even by inexperienced operators.

Disadvantages

Boiling of certain samples, such as ethanol and water, will result in loss of samples collected by the experimenter. In operation, boiling can usually be prevented by carefully adjusting the working intensity of the vacuum pump or the temperature of the heating pot during the mixing stage of the distillation process.

Or by adding anti-boiling particles to the sample. For samples that are particularly difficult to distill, including samples that are prone to foaming, the rotary evaporator can also be equipped with special condenser tubes.

How to choose a rotary evaporator

Before purchasing a rotary evaporator, it is necessary to clarify some questions, such as the amount of distillation at one time, the approximate number of samples that need to be distilled per day, what solvents are expected to be distilled, what is the approximate range of the boiling points of the solvents, and whether these solvents are Flammable, explosive or toxic and harmful solvents. After determining the experimental requirements and the type of solvent to be distilled, you can start purchasing a rotary evaporator.

1. Clarify the specifications of the rotary evaporator

The specifications of the rotary evaporator are usually distinguished by the volume of the evaporating flask. The size of the evaporating flask required depends on the quantity of the material to be evaporated. Generally speaking, 2L, 3L and 5L rotary evaporators are suitable for small laboratory experiments; 5L, 10L and 20L are suitable for pilot test; 20L and 50L are suitable for pilot test and production. Of course, under special circumstances, the volume of the evaporating flask can also be expanded by means of the continuous feeding pipe, thereby expanding the volume of one continuous distillation to a certain extent.

2. Clarify the distillation tasks that the rotary evaporator needs to complete

2.1. Distillation efficiency

The distillation efficiency of the rotary evaporator determines the number of samples that can be distilled per day. In the case of the same solvent, the higher the distillation efficiency, the greater the number of samples to be distilled. If the sample volume is large, you need to pay more attention to the distillation efficiency when purchasing a rotary evaporator.

2.2. Security risk assessment

The safety risk of distillation mainly comes from the solvent and heating medium of distillation.

1) If the heating medium is silicone oil, the ignition point should be at least 25°C higher than the high temperature of the heating pot.

2) If the distillation solvent has flammable and explosive properties, the explosion-proof glass component can be used. After the distillation is completed, it is good if the instrument can automatically deflate, so as to avoid manual deflation too fast and cause an explosion.

3) To optimize the laboratory environment, a secondary condensing device can be selected to maximize the recovery of the distillation solvent.
