Dual Purpose (Oven/Incubator), DOI-E Series

  1. Volume: 30L, 45L, 65L, 85L, 125L, 230L
  2. Temp.range: Incubator:RT+5-80℃; Drying oven:80-300℃
  3. Temp. Uniformity: Incubator: ±1.0℃; Drying; oven: ±2.5%
  4. Temp.control: PID Two temperature section intelligent PID
  5. Cycle Mode; Forced convection

Share the product




1.Horizontal air circularly by double Air ducts, high efficiency and high Uniformity.

2.PID controller, with over-temperature protection function.

3.With Oven/Incubator change switch,  fan switch; and high temperature blast motor, LED digital display

4.New anti-hot handle.

drying-oven 1. LCD temperature controller. SSR to make sure the safety

2. High precision digital independent temperature limiter

drying-oven New anti-hot handle



Model DOI-30E DOI-45E DOI-65E DOI-85E DOI-125E DOI-230E
Volume 30L 45L 65L 85L 125L 230L
Cycle Mode Forced convection
Function Temp. range Incubator:RT+5-80℃
Drying oven:80-300℃
Temp. Resolution Ratio 0.1℃
Temp. Motion ±1℃
Temp. Uniformity Incubator:±1.0℃
Drying oven:±2.5%
Structure Inner Chamber Mirror Stainless Steel
Outer Shell Cold rolling steel electrostatic spraying exterior
Insulation layer High quality rock wool board(with CE)
Heater Stainless steel heater
Exhaust hole φ28mm top(with function of test hole)
Controller Temp. control mode PID Two temperature section intelligent PID
Temp. setting mode Touch button setting
Temp. display mode DOI-E type: LED Digital Display
Timer 0-9999min(with timing wait function)
Operation Fixed temperature operation
function timing function, auto stop
Additional function DOI-E model: Sensor deviation correction, temperature overshoot self-tuning, internal parameter locking, power-off parameter memory
Sensor Pt100
Accessory Shelf 2
Shelf frame 4
Specification Load per rack 15kg
Shelf space 35mm
Power Supply AC110/220V±10%, 50/60Hz
Consumption 800W/ 1200W/ 1600W/ 2000W/ 2300W/ 3000W/
3.6A 5.5A 7.2A 9.0A 10.5A 13.6A
Internal Size(W*D*H) 310*310*310mm 350*350*350mm 400*360*450mm 450*420*450mm 500*450*550mm 600*500*750mm
External Size(W*D*H) 460*510*695mm 500*550*735mm 550*550*840mm 590*610*830mm 636*680*915mm 730*680*1250mm
Package Size(W*D*H) 550*585*845mm 590*625*885mm 640*635*985mm 690*690*985mm 740*725*1085mm 860*790*1400mm
NW/GW 33/37kg 37/43kg 44/49kg 50/56kg 60/66kg 94/120kg
Optional Accessories: DOI-E model: Shelf;



drying oven packaging



drying oven
