- Work Surface Height: 750mm
- Airflow Velocity: Adjustable, 0.2~0.5 m/s
- HEPA Filter Efficiency: > 99.995% at particle size of 0.3 μm
- Control System: Microprocessor controller with LCD display
Laminar Flow Cabinet, Horizontal Type, LCB-HF Series
Description
Horizontal Laminar Flow Cabinet provides a sterile work zone through a purified air that travels in a horizontal, unidirectional stream and leaves the main work chamber across the entire open front of the cabinet.
Applications
- Plant tissue culture
- Media plate preparation
- Electronics inspection
- Medical device assembly
Advantages
Humanized Features
- Ergonomic Control Panel Location, centered and angled down for an easy reach & viewing.
- Brushed stainless steel work surface is for easy cleaning
- The non-direct light source design can effectively relieve the operator’s visual fatigue under the condition of ensuring the illumination
- Intuitive and easy-to-use microprocessor controller with LCD display, graphical and digital display of the operating status of each function, such as filter life, UV life etc.
Safety Features
- Front sliding sash interlock with fan and UV lamp
- UV sterilization with UV lamp timing function
- Front sash and side windows are made of UV-resistant tempered glass
- The host and sockets have independent capacitors to prevent current overload
Convenience Features
- Memory function in case of power-failure.
- HEPA filter and UV life indicators facilitate a timely replacement plan
- Two side glass windows installed for easy experiment observation
- Easy-to-change pre-filter installed could extend the HEPA filter’s lifetime
- Equipped with temperature sensor to show the real temperature during operation
- Waterproof socket provide convenience for small instruments to be used in the operating area
Specifications
| Model | LCB-H3F | LCB-H4F | LCB-H5F | LCB-H6F | |
| External Dimensions
(W*D*H)(mm) |
1050*805*1950 | 1320*805*1950 | 1625*805*1950 | 1930*805*1950 | |
| Internal Dimensions
(W*D*H)(mm) |
950*490*574 | 1220*490*574 | 1525*490*574 | 1830*490*574 | |
| Control System | Microprocessor controller with LCD display, graphical and digital display of the operating status of each function. | ||||
| Work Surface Height | 750mm | ||||
| Airflow Velocity | Adjustable, 0.2~0.5 m/s | ||||
| HEPA Filter | Efficiency | > 99.995% at particle size at 0.3 μm | |||
| Dimensions(W*D*H)(mm) | 930*500*70 | 1190*500*70 | 1505*500*70 | 905*500*70 | |
| Quantity | 1pc | 2pcs | |||
| Pre-Filter | Material | made of washable polyester fiber | |||
| Dimensions(W*D*H)(mm) | 500*425*2 | 800*425*2 | 800*425*2 | 800*425*2 | |
| Quantity | 1pc | ||||
| Sound Emission | ≤62dB(A) | ||||
| Lighting Lamp | 6.5W*1 | 9.6W*1 | 9.6W*1 | 6.5W*2 | |
| LED type, Intensity ≥900Lx | |||||
| UV Lamp | 20W*1 | 30W*1 | 30W*1 | 18W*2 | |
| With timing function, Interlock with front sliding sash. Emission of 253.7 nanometers for best sterilization effect. | |||||
| Power Consumption | 165W | 305W | 405W | 510W | |
| The power consumption does not include external device connected via power socket | |||||
| Cabinet Construction | Main Body: Electro-galvanized steel with antimicrobial powder coating | ||||
| Work Zone: Stainless steel, grade 304 | |||||
| Manual Sliding Sash: 5 mm UV resistant tempered glass with counter-balance system and ergonomic handle | |||||
| Side Windows: 5 mm UV resistant tempered glass | |||||
| Electricity | AC220V ±10%, 50/60Hz,1P | ||||
| Standard Accessories | Base stand*1;
LED lamp*1(only 2 for LCB-H6F); UV lamp*1(only 2 for LCB-H6F); Waterproof socket*2； Foma casters*4 |
||||
| Optional Accessories | Wind speed sensor; Gas tap; Water tap; Casters with brakes; Hook and hook bar | ||||
| Shipping Weight（kg） | 220 | 260 | 300 | 340 | |
| Shipping Dimensions（W*D*H）(mm) | 1190*1010*1430 | 1470*1020*1430 | 1010*1780*1440 | 2080*1020*1440 | |
| Shipping Volume (m3) | 1.7 | 2.3 | 2.55 | 3.1 | |
