PCR Machine, PCR-482

  • Independently controlled 4 temperature zones
  • PC on-line function
  • Printing function
  • Gradient type
  • Capacity: Double 48×0.2ml
  • Max. Heating/Cooling rate: 5℃/s, 4℃/s
  • Temperature uniformity: ≤±0.2℃

Share the product

Category:

Description

PCR-482 PCR machine uses customized Marlow (US)  peltier. Its max. ramping rate is 5 ℃/s and cycle times is more than 1,000,000. The product combines a variety of advanced technologies: Windows system, color touch screen; independently controlled 4 temperature zones; PC on-line function; printing function; big storage capacity and support USB device. All above functions allow PCR’s excellent performance and meet higher experiment’s need.

Advantages

  • 8 pcs long service life Peltier heating units and form 4 circuits to control 4 temperature zones and allow double block gradient function;
  • Reinforced aluminum module with anodizing technology can keep rapid heating-conducting property and have enough corrosion resistance;
  • High heating and cooling rate, ramping rate 5 C/s, can save your precious time, Two blocks independently controlled and can run 2 different PCR programs simultaneously;
  • Stepless adjustable hot lid with pressure-protection, fit tubes of different heights to avoid tube melt and evaporation; Android operating system, capacitive touch screen, high-definition TFT display (8”, 800×600 pixels, 16 colors) with graphical interface provides easy use for setting up and monitoring
  • Built-in 11 standard program file template, can quickly edit the required files
  • Folder management, user can build directory;
  • The running program and left time can be displayed in real time, allow to edit file when program is running;
  • One-click quick incubation function can meet experiment’s needs such as denaturation, enzyme cutting/enzyme-link and ELISA;
  • Internal flash memory for 10000 typical PCR files in free configurable folders
  • Hot lid temperature and hot lid work mode can be set to meet different experiment’s need:
  • Automatic restart after power failure. When power is restored it can continue to run unfinished program;
  • GLP report records every step to provide accurate data support for experiment result analysis;
  • User Login Management, three-tier permission, password protection function to ensure data security;
  • Support U disk to get PCR data, to update software, and USB mouse can also be used to control the PCR instrumen
  • Built-in WIFI module, one machine can control multiple PCR machines at the same time through mobile APP or PC software
  • Support email-alert function when experiment is over.

Specifications

Model PCR-482
Capacity Double 48×0.2ml
Temperature Range 0-105℃
Heating Rate 5℃/s
Cooling Rate 4℃/s
Uniformity ≤±0.2℃
Accuracy ≤±0.1℃
Display Resolution 0.1℃
Temperature Control Block/Tube
Ramping Rate Adjustable 0.1-5℃
Gradient Temp. Range 30-105℃
Gradient spread 1-30°C
Hot Lid Temperature 30-115°C
Number of Programs 10000+(USB FLASH)
Max. No.of step 30
Max. No.of cycle 200
Time Increment/Decrement 1Sec-600 Sec
Temp.Increment/Decrement 0.1-10℃
Pause Function Yes
Auto Data Protection Yes
Hold at 4℃ Forever
Touchdown Function Yes
Long PCR Function Yes
Language English
Computer Software Yes
Mobile phone APP Andriod
LCD 8 inch, 800×600 pels
Communication USB2.0,LA N,WIFI
Dimensions(L×W×H) 390mm×270mm×255mm
Package Dimension (W*D*H) (mm) 560*430*430
Weight 9 Kg/12.7
Electricity 100-240 VAC , 50/6 0Hz , 60 0W
