| Model |
MSC-T08B |
| Optics |
Finite Distance Optical System |
| Observation Tubes |
Seidentopf binocular head |
| Optical Coating |
Transmittance ≥ 95% |
| Eyepiece |
WF10× *WF16 |
| Objective |
Achromatic objective：4X，10X，40X，100X |
| Nosepiece |
Quadruple nosepiece |
| Stage |
Carrier platform: double-layer mobile platform, platform size: 105 × 115mm, moving range: 60 × 20mm |
| Condenser |
Abbe condenser N.A. 1.25 |
| Focusing |
Focusing system: Coarse and micro coaxial focusing, micro grid value of 0.01mm, focusing range of 20mm |
| Illumination |
LED illumination, brightness adjustable |
| Electricity |
100-240V AC,50/60Hz |
| Package Dimension (W*D*H) (mm) |
340*280*450 |
| Gross Weight (Kg) |
4.2 |
