Fat Analyzer, Semi-auto Type, FTA406

  1. Temperature range: Room temperature+5℃~ 280℃
  2. Measuring range: 0 ~ 100%
  3. Temperature accuracy: ±1℃
  4. Sample weight: 0.5 ~ 15g(generally 2 ~ 5g,depending on sample)

Share the product

Description

1.Integral metal heating, wide scope and high precision of temperature control.

2.Electric circuit is isolated from the extraction space, ensuring device security.

3.Timer and timing functions are available.

4.Over-temperature alarming and timer reminding functions are available

5.Triple alarms i.e. sound, light, LCD screen word prompts are available.

6.Abundant interface contents give simultaneous display of given temperature, actual temperature, given time and heating time.

7.The lifting connection of linear bearing conduction technique gives smooth and comfortable lifting operation.

8.Intelligent man-machine dialogue control system.

9.Exclusive air insulation technique leaves the case in room temperature, has thermal insulation and temperature maintenance two functions.

10.4.3” LCD screen and microcomputer control systemare adopted.

Specifications

Model
FTA406
Temperature range Room temperature+5℃~ 280℃
Measuring range 0 ~ 100%
Temperature accuracy ±1℃
Sample weight 0.5 ~ 15g(generally 2 ~ 5g,depending on sample)
Capacity per batch 6pcs/batch
Solvent cup volume 80mL
Solvent recovery ≥80%
Shortened extraction time 20 ~ 80%
Power supply 220VAC±10%, 50Hz
Power 1KW
Dimensions 650mm×320mm×715mm
Net Weight 35Kg
