Gel Maker, DBI-GM5

  • LED display
  • Capacity: 1-5mL, 10 hole areas(Heating or cooling)
  • Temperature Setting Range: 10-90℃
  • Heating Speed (RT.-90℃): <10min
  • Cooling Speed (90℃-RT.): <4min

Share the product



Gel Maker is an important equipment to make blood plasma into autologous collagen.It adopts advanced cooling and heat system to control the temperature accurately.It can prepare plasma into protoplasmic gels, replacing the high cost filler.It has good features of non-toxic and no side effects, promotes better activity of growth factors and is widely used in the medical aesthetic industry.

  • Double LEDs for independent display of temperature and time;
  • temperature of 90 ℃, with support for timed and continuous operation.
  • With two separate bins: a heating bin and a cooling bin. individually timed and independent of each other,each bin can store syringes ranging from 1-5mL at the same time.
  • Two programs, easy to start the procedure by one key.
  • A sophisticated cooling system eliminates the need for cumbersome cooling of heated protoplasmic gels.
  • Safe and stable, with a timer that starts when the temperature rise reaches the set temperature and an alarm when the machine finishes running.


Model DBI-GM5
Capacity 1-5mL,10 hole areas (Heating or cooling)
Temperature Setting Range 10-90℃
Temperature Control Accuracy ±1℃
Temperature Increments 1℃
Temperature Display 0.1℃
Safe Temperature 110℃
Timing Function Yes
Time Setting Range 0s-99min59s
Time Increments 1s
Display LED
Max. Heating Speed (RT.-90℃) <10min
Max. Cooling Speed (90℃-RT.) <4min
Run Time Timing/continuous operation
Preloaded Program 2
Power 260W
Electricity AC 110/220V, 50/60Hz
Permissible Ambient Temperature and Humidity 5-40℃, 80%RH
External Dimension(L*W*H) 330*220*130mm
N.W./G.W. 4.2kg/5.5kg
Shipping Dimension(L*W*H) 405* 300* 215mm
