Description

1、Heating power and stirring speed is stepless adjustable.

2、With adjustable Thermometer Rack, Stainless Steel Rods and the Stir Bar.

Specifications

Model		Hotplate	Magnetic Stirrer	Combination Stirring Hotplate	Hotplate	Magnetic Stirrer	Combination Stirring Hotplate
Model		HPT-380-2A	MGS-2	HPS-380-2	HPT-380-3A	MGS-3	HPS-380-3
Function	Max. Volume (ml)	–	2000	2000	–	5000	5000
	Speed (r.p.m)	–	100~2000	100~2000	–	100~2000	100~2000
	Working time	Continuous	Continuous	Continuous	Continuous	Continuous	Continuous
	Minimum revolution (r.p.m)	–	100	100	–	100	100
	Max.Temp. (℃)	380	–	380	380	–	380
Structure	Exterior	Cast aluminium, Surface spraying
	Plate size (mm)	120×120	120×120	120×120	170×170	170×170	170×170
	Driving mode	–	Motor	Motor	–	Motor	Motor
	Motor power (W)	–	10	10	–	20	20
	Heating Power (kW)	0.18	–	0.18	0.5	–	0.5
	Stir bar	–	PTFE	PTFE	–	PTFE	PTFE
Controller	Continuous operation	Yes	Yes	Yes	Yes	Yes	Yes
	Setting mode	Scale	Scale	Scale	Scale	Scale	Scale
	Speed display mode	–	Scale	Scale	–	Scale	Scale
	Timer	No	No	No	No	No	No
	Operation function	No	No	No	No	No	No
	Temp. Sensor	No	No	No	No	No	No
Specification	Exterior size (WDH) (mm)	200×120×90	200×120×90	200×120×90	265×185×190	265×185×190	265×185×190
	Packing size (WDH) (mm)	250×180×120	250×180×120	270×180×190	280×210×220	280×210×220	320250230
	Plate size (mm)	120×120	120×120	120×120	170×170	170×170	170×170
	Plate load (kg)	3	3	3	10	10	10
	Power supply (50/60Hz) Current rating	110V or 220V	110V or 220V	110V or 220V	110V or 220V	110V or 220V	110V or 220V
	NW/GW (kg)	1.9/3	1.9/3	1.9/3	2.2/3.4	2.2/3.4	2.2/4
