Hotplate Magnetic Stirrer, Temp. 380°C, HPS-380-1

  1. Heating temperature rangeRoom temp: +5ºC-380ºC
  2. over heat protection: 420ºC
  3. Temperature display accuracy: ±0.1ºC
  4. External temperature sensor: PT1000 (accuracy ±0.5ºCJ)
  5. Control accuracy of sensor: ±20rpm

Share the product




  1. Max. heating temperature is 380°C.
  2. High resolution LCD displays actual temperature and speed.
  3. Brushless DC motor is maintenance free.
  4. Aluminum cover with ceramic work plate, allows for immediate heat transfer.
  5. External temperature control is possible with temperature sensor PT1000.
  6. Digital temperature control with max. temperature at 380°C.
  7. Digital speed control with max. speed up to 1500rpm.
  8. Max. stirring quantity of H2O at 5L.



Specifications HPS-380-1
Work plate dimension [W×H] 140×140 mm
Work plate material Aluminum cover with ceramic coating
Motor type Brushless DC motor
Stirring positions 1
Max. stirring quantity [H2O] 5L
Max. magnetic bar [length] 50mm
Speed range 200-1500rpm
Speed display LCD
Temperature display LCD
Heating temperature range Room temp: +5ºC-380ºC
Over heat protection 420ºC
Temperature display accuracy ±0.1ºC
External temperature sensor PT1000 (accuracy ±0.5ºCJ)
Control accuracy of sensor ±20rpm
Protection class IP21
Motor rating input 2.4W
Motor rating output 1.8W
Power 510W
Heating output 500W
Voltage 100-120/200-240V, 50/60Hz
Dimension [W×D×H] 320×180×108mm
Weight 2.2kg
Permissible ambient temperature and humidity 5-40ºC, 80%RH
