LED Hot Plate, Temp. 550°C, HPT-550

  1. Heating temperature range: Room temp.-550°C, increment 5°C
  2. Control accuracy of work plate: ±10°C
  3. Safety temperature: 580°C
  4. Temperature display: LED
  5. Temperature display accuracy: ±1°C
  6. External temperature sensor: PT1000(±0.5°C)

Share the product


•LED screen shows temperature
•Max. temperature up to 550°C
•Separate safety circuits with fixed safety temperature of 580°C
•External temperature control is possible by connecting the temperature sensor (PT 1000) with an accuracy at ±0.5°C
•Glass ceramic work plate provides excellent chemical-resistant performance and most efficient heat transfer
•The “HOT” warning will flash if the work plate temperature is above 50°C even when the hotplate is turned off


Specifications HPT-550
Work plate dimension [WxD] 184x184mm (7 inch)
Work plate material Glass ceramic
Heating position 1
Heating temperature range Room temp.-550°C, increment 5°C
Control accuracy of work plate ±10°C
Safety temperature 580°C
Temperature display LED
Temperature display accuracy ±1°C
External temperature sensor PT1000(±0.5°C)
Heating warning 50°C
Protection class IP21
Power 1010W
Voltage Frequency 100-120/200-240V,50/60Hz
Heating Power 1000W
Dimension [WxDxH] 215x360x112mm
Weight 4.5kg
Permissible ambient temperature and humidity 5-40°C, 80%RH
