- Capacity(L/cu.ft):105/3.7,485/17.12
- Temp.Range(℃):-86～-40℃
- Advanced Cooling System: High performance compressor, reasonable refrigeration layout,more stable refrigerant, faster cooling
- Stable and high precise temperature control:Accuracy up to 0.1℃; Can run smoothly at the lowest temperature for a long time.
- Convenient after-sales service:2 years warranty
Ultra Low Temperature Freezer, ULF86-H Series
Description
Features of Ultra Low Temperature Freezer
1. Wide available voltage range: 187V~242V.
2.Wide temperature range :10℃~32℃ambinet temperature can reach -86℃.
3. Accurate Temperature control technology to make the temperature maintain -86℃~-40℃.
4. 304 stainless steel inner chamber for friendly using and easy cleaning.
5. The single level optimization of auto cascade refrigeration system design, keep fast cooling speed and energy saving.
Safety
1. Visual and audible alarm system: High/low temperature, sensor error.
2. Power failure protection: turn on delay of the cooling system when power failure, restart delay protection.
3. Keyboard lock, password protection to avoid set parameter randomly.
4. Special noise reduction design.
5. 100mm insulation layer keep perfect performance.
Humanized design
1. 4 casters with stopper for easy moving and fixation.
2. Standard 25mm test hole for easy connecting to temperature monitoring systems.
3. Safety door lock design ,open the door to prevent abnormal.
4. Large screen digital display for easy observation.
Specifications
| Model | ULF86-H110 | ULF86-H490 | |
| Specifications | Shelf/drawer QTY | / | / |
| Cooling | Direct cooling | Direct cooling | |
| Defrost | Manual | Manual | |
| Refrigerant | R4001 | R4001 | |
| Power consumption(kWh/24h) | 4.79 | 13.5 | |
| Noise(db) | 50 | 54.5 | |
| Ambient temperature(℃） | 10~32℃ | 10~32℃ | |
| Temperature range(℃） | -40~-86℃ | -40~-86℃ | |
| Cooling system | Compressor brand/QTY | CUBIGEL/1 | SECOP/1 |
| Sensor | PTC | PTC | |
| Temperature controller | Microprocessor | Microprocessor | |
| Display | Digital display | Digital display | |
| Power | Voltage/frequency(V/Hz) | 220/50Hz | 220/50Hz |
| Power(W) | 500W | 670W | |
| Current(A) | 2.53A | 3.16A | |
| Material | Inside material | Stainless steel | Stainless steel |
| Outside material | Color sprayed steel | Color sprayed steel | |
| Insulation | PURF | PURF | |
| Size | Capacity(L/cu.ft) | 105/3.70 | 485/17.12 |
| NW./GW.(kg) | 65/90 | 130/150 | |
| Exterior size(W×D×H)(mm) | 680*580*935 | 1695×840×962 | |
| Interior size(W×D×H)(mm) | 480*380*665 | 1455.5*525.2*674 | |
| Package size(W×D×H)(mm) | 770*760*1040 | 1765×900×1060 | |
| CBM | 0.59 | 1.75 | |
| 20GP/40GP/40HQ | 24/51/51 | 6/13/13 | |
| Frozen Racks | Racks | 4(11X1,6X1) | 30(11X1,6X1) |
| Boxes (2 Inches) | 34 | 300 | |
| Samples(2ml) | 3400 | 30000 | |
| Alarm | High/low temperature | Y | Y |
| Power failure | / | / | |
| Abnormal voltage | / | / | |
| Sensor error | Y | Y | |
| Filter screen check | / | / | |
| Thermostat failure | Y | Y | |
| Low battery | / | / | |
| Condenser clean | / | / | |
| High ambient temperature | / | / | |
| Door ajar | / | / | |
| Power failure backup system(alarm) | 12h | 12h | |
| Accessories | Castor | Y | Y |
| Inside door | / | / | |
| Test hole QTY/diameter | 1/25MM | 1/25MM | |
| USB port | / | / | |
| Chart recorder | / | / | |
| Data logger | / | / | |
| Remote alarm port | / | / | |
| Optional | CO2 back up system | / | / |
| LN2 back up system | / | / |
| Category | Title | File type/size | Download |
| Catalog | refrigeration equipment catalog | PDF(2 MB) | download |
