Name: Low Temperature Biomedical Freezer, -25℃, LF25-H Series - Infitek
Brand: Bioevopeak

Low Temperature Biomedical Freezer, -25℃, LF25-H Series

The -25°C Low Temperature Biomedical freezer meets medical, scientific and industrial refrigeration needs, with large capacity, space-saving design, precise control, stability, fast cooling and other features, it is an ideal choice for hospital and laboratory sample storage.

Capacity (L): 105, 485, 305
Temperature range (℃）: -25~-10℃
Advanced Cooling System: Reasonable refrigeration layout,more stable refrigerant，High cooling efficiency and fast cooling speed.
Stable and high precise temperature control: Accuracy up to 0.1℃; Can run smoothly at the lowest temperature for a long time
Convenient after-sales service: 2 years warranty

Share the product

Description

Key Features of Biomedical Freezer

Chemically stable, CFC-free, commercially available and environmentally safe refrigerant.
Microprocessor control, adjustable temperature range: -25℃to –10℃
LED digital display and increment range at 0.1℃~1℃.
Permanently lubricated cooling fan for safety and longevity.
Wide voltage band for 187V~242V.
Door lock design to avoid abnormal door open.
Big screen for easy observation.
Standard testing hole.

Safety

Multiple malfunction alarms to detect high and low temperature, sensor error, power failure, temperature controller malfunction.
Two types of alarm indications: audible buzzing and visual flashing light.

Reliability

High density CFC-free urethane foam insulation.
Standard with 25mm test hole.
Power failure protect: the device would be attack by the high current when all devices restart simultaneously, the start-delay function would protect device from the damage.

Specifications

	Model	LF25-H110	LF25-H490	LF25-H310
Specifications	Shelf (drawer)	/	/	/
	Cooling method	Direct cooling	Direct cooling	Direct cooling
	Defrost	Manual	Manual	Manual
	Refrigerant	HC-R290	HC-R290	R134a
	Power consumption(kWh/24h)	1.59	3.45	1.5
	Noise（db)	46	55	52
	Ambient temperature (℃）	10~32℃	10~32℃	10~32℃
	Temperature range (℃）	-10~-25℃	-10~-25℃	·-10~25℃
Cooling system	Compressor brand/QTY	DONPER/1	CUBIGELN/1	China brand
	Sensor	NTC	NTC	NTC
	Temperature controller	Microprocessor	Microprocessor	Microprocessor
	Display	Digital display	Digital display	Digital display
Power	Voltage/frequency (V/Hz)	220/50Hz	220N50Hz	220/50Hz
	Power (W)	174W	295W	106W
	Current (A)	1.48A	2.45A	0.92A
Material	Inside material	Color sprayed steel	Stainless steel	Color sprayed steel
	Outside material	Color sprayed steel	Color sprayed steel	Color sprayed steel
	Insulation	PURF	PURF	PURF
Size	Capacity (L/cu.ft)	105/3.70	485/17.12	305L
	NT./GT. (kg)	41.8/54	124/138	74.2/87
	Exterior size(WDH)(mm)	615570880	1655×755×915	1135725890
	Interior size(WDH)(mm)	480380665	1455×525×665	1000520665
	Package size(WDH)(mm)	7006401010	1710×885×1020	12237771005
	CBM	0.42	1.66	0.96
	20GP/40GP/40HQ	27/57/57	12/26/26	26/56/56
Alarm	High/low temperature	Y	Y	Y
	Power off	Y	Y	Y
	Sensor malfunction	Y	Y	Y
	Ambient temperature (℃)	/	/	/
	Abnormal voltage	/	/	/
	Temperature controller malfunction	Y	Y	Y
	Door ajar	/	/	/
	Power failure backup system(alarm)	12H	12H	12H
Accessories	Caster	Y	Y	Y
	Test hole	1/25MM	Optional	1/25mm
	USB port	/	/	/
	Data logger	Optional	Optional	Optional
	Remote alarm	/	/	/
