Low Speed Centrifuge, CFG-550JP

  • Max.Speed: 6000rpm
  • Max.RCF: 5502xg
  • Max.Capacity: 750mlx4

Share the product

Description

Description

CFG-550JP Low Speed Centrifuge adopts microcomputer control, large-screen color LCD display, and full touch-screen operation interface to directly set the working program, RCF, speed, time, acceleration and deceleration, and rotor model.

Features

  1. Brushless AC variable frequency motor drive and special drive module ensure the reliability of the circuit.
  2. Double door cover lock system, starting means locking, ensuring safe operation.
  3. Provides 20 kinds of working program storage, users can freely program and call theirworking parameters, which is easy to use and improves work efficiency.
  4. Provide 15 kinds of acceleration/deceleration; User can set one group of acceleration and deceleration arbitrarily according to the sample requirements.
  5. Two timing functions: at set rpm and start timing, and the jog is short spin function.
  6. Differential centrifugation: Five differential centrifugation programs are reserved, and users can set them according to their needs.
  7. Double-layer steel structure and stainless steel centrifugal chamber to avoid corrosion.
  8. Automatic balance and imbalance protection. When an error or imbalance occurs, an audible alarm signal will be issued and the centrifuge will automatically stop running.
  9. Easily adjust speed, RCF, time and temperature during operation without
  10. The shortest acceleration / deceleration time≤
  11. Countdown function : The countdown in seconds,real time display of remaining working time.
  12. Can customize 485 communication interface function.
  13. Sunken exhaust passage prevents aerosol pollution during centrifugation.

Specifications

Model CFG-550JP
Max.Speed 6000rpm
Max.RCF 5502xg
Max.Capacity 750mlx4
Speed Accuracy ±10rpm
Timing Range 1s~99h59min59s/Jog (short spin)
Sound Emission ≤62dB
Electricity AC 220V, 50Hz, 10A
Power 600W
Dimension(W*D*H) 640*515*450mm
N.W./G.W. 60kg/83kg
Package Dimension(W*D*H) 750*645*630mm

Rotor Configuration

Rotor Capacity Max. Speed Max.RCF
NO1:

Swing Rotor

Cross

750mlx4 4200rpm 3727xg
Adapter:500mlx4,250ml(round bottom)x4,250ml(conical)x4,

100mlx12,50ml(conical)x20, 50ml(round bottom)x28, 15ml(conical)x56,

10ml(vacuum tube)x76,3ml/5ml/7ml(vacuum tube)x96,5mlx148

NO2:

Cap Remover

Swing Rotor

Cross

5mlx96 4200rpm 3727xg
Adapter: 5mlx96
NO3:

Anti-pollution

Swing Rotor

Cross

750mlx4 4200rpm 3727xg
Adapter:500mlx4,250ml(round bottom)x4,

100mlx12,50ml(conical)x20, 50ml(round bottom)x28, 15ml(conical)x56,

10ml(vacuum tube)x76,3ml/5ml/7ml(vacuum tube)x96, 5mlx148

NO4:

Swing Rotor

Cross

(eight claws)

100mlx16 4200rpm 3727xg
Adapter:100mlx16, 50mlx16, 10mlx64
NO5:

Swing Rotor

Cross

(honeycomb briquette)

5mlx148 4200rpm 3451xg
5mlx148
NO6:

Angle Rotor

50mlx6 6000rpm 5502xg
NO7:

Microplate

96(deep well plate)×2 5000rpm 3530xg
96(microplate)×2×2 5000rpm 3530xg
NO8:

Microplate

96(deep well plate)×4 4000rpm 3667xg
96(microplate)×4×2 4000rpm 3667xg
