Ultrasound Machine, Black & White, US-H360

  1. One-key calls full-screen function
  2. One-key calls for case information and entry
  3. Report: Abdomen, OB, Cardiac, Urology

Share the product


  • 15inch LED display
  • Built-in rechargeable battery
  • Rich clinical measurement software
  • Stable operation platform
  • Single probe connector,can work with probe extender
  • Report: Abdomen, OB, Cardiac, Urology
  • Offer suitcase for package


The equipment has excellent image quality, all-round image processing capabilities, including comprehensive clinical diagnosis and improved doctor productivity, online image storage and raw data, etc. The time-saving mode is used in the emergency department.


Brilliant Ergonomics

  • Multiple display modes , realizes multi – Angle, multi – directional comparative observation
  • One-key calls full-screen function
  • One-key calls for case information and entry

Excellent Image Quality

  • Full digital imaging technology with high precision

Powerful Workflow

  • Based on Windows operating platform, faster running speed, more rich functions
  • Strong expansible functions , convenient for system

upgrading and quick maintenance


Model US-H360
Monitor 15 inch LED medical display, able to reverse it above 160 degree
Scanning method Convex/Linear/Micro-convex
Probe sockets 1
Modes B, B+B, 4B, B+M, M, PW
Hard disk ≥128G
Zoom 4, 30 levels (adjustable)
Cine loop ≥1500 frames
Body marks 105 kinds
Pseudo color 8
Scanning range 7.5: 79-100%;3.5: 46-60%;6.0: 68-90%
Single image storing time ≤1 second
Grap scale 256 Levels
Dynamic range 65 Levels
Gain 2-100
Frame correlation 0-7
Line correlation 0-5
Line density 2
Harmonic wave 2 levels
Net weight 6.7Kg
Measurement Distance, angle, area stenosis ratio, ventricular output, heart rate, and other professional software measurement package
Interface ports VGA, LAN, USB *2
Language Chinese/English/Russian
